Nickle lab reactor system

Nickel is an important strategic metal in nonferrous metals, with advantages of corrosion resistance, heat resistance, strong strength and good plasticity. It has been widely used in steel, electroplating, vacuum, petroleum, chemical and other industries.

Features

1. High melting point, with excellent corrosion resistance in normal temperature and high temperature.

2. With special physical properties.

3. Good press working performance in hot and cold environment.

4. Good corrosion resistance in reductive medium and neutral medium.

Parameters

Volume: 0.1L~50000L

Working pressure: vacuum ~45MPa

Working temperature: low temperature~ 500℃

Mixing speed: 20-1500r/min

Motor power: 40~100KW

Heating type: electrical heating, water circulation, conduction oil, steam and far infrared ray heating, etc.

Medium discharging type: top discharging and bottom discharging

Mixing shaft: the self-lubricating wear-resisting shaft sleeve is suitable for mixing various kinds of mediums

Mixing type: paddle type, anchor type and screw belt type.

Sealing type: magnetic sealing, mechanical sealing and packing sealing.

Motor: normal DC motor, or common used DC servo motor, or explosion-proof motor according to client’s requirements.
