Titanium TA1 cladding plate 5000L reactor

Parameters

Volume: 0.1L~50000L

Working pressure: vacuum ~45MPa

Working temperature: low temperature~ 350℃

Mixing speed: 20-1500r/min

Motor power: 40~100KW

Heating type: electrical heating, water circulation, conduction oil, steam and far infrared ray heating, etc.

Medium discharging type: top discharging and bottom discharging

Mixing shaft: the self-lubricating wear-resisting shaft sleeve is suitable for mixing various kinds of mediums

Mixing type: paddle type, anchor type and screw belt type.

Sealing type: magnetic sealing, mechanical sealing and packing sealing.

Motor: normal DC motor, or common used DC servo motor, or explosion-proof motor according to client’s requirements.

Main material: Titanium TA1 + Q345R cladding plate

Application: As titanium has advantages of high strength, superior heat resistance, anti-corrosion and fracture toughness, etc., it is favorable in aviation, aerospace, petrochemical, medical and geological industries.
