NO.

Item

Technical parameters

1

Nominal volume

1500L

2

Material

The material of contacting the reactions materials parts: 0Cr18Ni9(304), 00Cr17Ni14Mo2(316L), 1Cr18Ni9Ti(321), Titanium(TA2, TA1), Nickel (Ni6), Tantalum, Zirconium, Hastelloy (C-276, C-22, C200, B2) or lined Teflon or other materials.

3

Design pressure

-0.1~16MPa

4

Design temperature

-196℃~350℃

5

Mixing speed

0~500r/min

6

Motor power

5.5~15KW

7

Heating power

According to the working temperature and heating type

Electrical heating power: 36~60KW

8

Motor connecting type

Vertical drive

9

Heating type

Outer jacket steam or oil heating, half-pipe jacket heating, inner coiler heating from heating furnace.

Electric heating, far infrared heating, high frequency heating.

Water , thermal oil or steam recycling through jacket by constant temperature heating bath.

10

Opening ports on the reactor kettle

Equip with necessary valves for ports, and pairs of flanges, need to know the flanges standard,temperature measurement and display, pressure gauge safety blasting with pressure gauge and safety explosion-proof device.

11

Mixing type

Paddle type, anchor type, impeller type, blade type, turbine type, scraper type or modular type, or choose other types combination according the reaction condition.

12

Mixing shaft

Adopt self-lubricating wear-resisting bushings, suitable for various media agitation.

13

Seal type

Magnetic seal, mechanical seal, packing seal

14

Discharging type

Upward discharging(dip pipe ) or downward discharging valve

15

Control box device

Equipped with PID or PLC control box on site

And also can equip with host computer software on-line monitoring, display and control which can achieve:

Programmed temperature display and control, accuracy ± 1 ℃ (or ±0.1 ℃);

Mixing Speed display and control;

Pressure display and control;

Level display and control;

PH display and control;

Flow display and control;

Valve open/close control, etc.

16

Other configurations

Customized design and manufacture, according to different requirements on the kettle cover, reactor body, inner mixing paddles or add additional devices(Such as condensation reflux device, constant pressure feed tank, receiving device, condenser, etc.). We can help customer to achieve their request, and also can equip necessary instruments as request.
