NO.

Item

Technical parameters

1

Nominal volume

1L

2

 Material

Reactor body: 0Cr18Ni9(304), 00Cr17Ni14Mo2(316L), 1Cr18Ni9Ti(321), Titanium(TA2), Nickel, Tantalum, Zirconium, Hastelloy or lined PTFE or cladding plate.

3

 Design pressure

 -0.1~15Mpa (0~15Mpa is our standrd type, if you meed higher pressure, the highest pressure can reach 40Mpa if need)

4

 Design temperature

 0~400 C,  (0~400C is our standrad type, if you need higher temperature, the highest temperature can reach 600C if need)

5

 Mixing speed

 0~1000r/min

6

 Motor power

 123W

7

 Heating power

1500~2000W

8

 Motor connecting type

 Vertical drive or lateral pull

9

 Heating type

Electrical heating,electromagnetic heating,microwave heating,heat conduction oil heating, steam circulation heating

10

 Opening ports on the reactor kettle

Gas phase port with needle valve, liquid phase port with needle valve and dip pipe, solid feed inlet with plug, temperature measurement and control with platinum resistance, pressure gauge safety blasting with pressure gauge and safety explosion-proof device, reactor cooling coil inlet and outlet with tap.

11

 Mixing type

 Paddle type, anchor type, impeller type, or choose other types according the reaction condition.

12

 Mixing shaft

 Adopt self-lubricating wear-resisting bushings, suitable for various media agitation.

13

 Seal type

 Magnetic sea

14

 Discharging type

 Upward discharging(dip pipe ) or downward discharging valve

15

 PID Control box

Temperature display and control, control accuracy±1℃; mixing speed display and stepless speed, heating power control and keep automatic constant temperature.

16

 Other configurations

 Customized design and manufacture, according to different requirements on the kettle cover, reactor body, inner mixing paddles or add additional devices(Such as condensation reflux device, constant pressure feed tank, receiving device, condenser, etc.)
