NO.

Item

Technical parameters

1

Nominal volume

20L

2

Material

Reactor body: 0Cr18Ni9(304),00Cr17Ni14Mo2(316L),1Cr18Ni9Ti(321),Titanium(TA2),Nickel, Tantalum, Zirconium, Hastelloy or lined PTFE.

3

Design pressure

-0.1~25Mpa

4

Design temperature

0~350 C

5

Mixing speed

0~1000r/min

6

Motor power

550W

7

Heating power

6KW

8

Motor connecting type

Vertical drive or lateral pull

9

Heating type

Electrical heating,electromagnetic heating,microwave heating,heat conduction oil heating, steam circulation heating

10

Opening ports on the reactor kettle

Gas phase port with needle valve, liquid phase port with needle valve and dip pipe, solid feed inlet with plug, temperature measurement and control with platinum resistance, pressure gauge safety blasting with pressure gauge and safety explosion-proof device, reactor cooling coil inlet and outlet with tap.

11

Mixing type

Paddle type, anchor type, impeller type, or choose other types according the reaction condition.

12

Mixing shaft

Adopt self-lubricating wear-resisting bushings, suitable for various media agitation.

13

Seal type

Magnetic seal

14

Discharging type

Upward discharging(dip pipe) or downward discharging (bottom valve)

15

PID Control box

Temperature display and control, control accuracy±1℃; mixing speed display and stepless speed, heating power control and keep automatic constant temperature.

16

Other configurations

Customized design and manufacture, according to different requirements on the kettle cover, reactor body, inner mixing paddles or add additional devices(Such as condensation reflux device, constant pressure feed tank, receiving device, condenser, etc.)
